Overview

Relevant Source Files

README.md compute/__init__.py compute/utils/parser.py

The NI Compute Subnet is a decentralized GPU compute marketplace operating on the Bittensor network as subnet 27. It enables miners to contribute GPU resources and earn rewards based on their computational performance, while validators measure miner capabilities and allocate resources to clients through a trustless, permissionless system.

This document provides a high-level overview of the system architecture, core components, and their interactions. For detailed installation instructions, see Installation and Setup. For specific component documentation, refer to the Validator System, Miner System, and Resource Allocation API sections.

System Architecture

The NI Compute Subnet consists of three primary components that interact through the Bittensor network and custom communication protocols:

graph TB
    subgraph "Bittensor Network"
        BT["Subtensor Blockchain"]
        META["Metagraph State"]
    end

    subgraph "Validator System"
        VAL["Validator Process<br/>neurons/validator.py"]
        POG["Proof-of-GPU Validation"]
        SCORE["Performance Scoring"]
        WEIGHTS["Weight Setting"]
    end

    subgraph "Miner System"
        MIN["Miner Process<br/>neurons/miner.py"]
        DOCKER["Docker Container Management"]
        SSH["SSH Resource Access"]
        HASHCAT["Hashcat PoW Challenges"]
    end

    subgraph "Resource Allocation API"
        API["RegisterAPI<br/>FastAPI Service"]
        ALLOC["Resource Discovery"]
        HEALTH["Health Monitoring"]
    end

    subgraph "Data Layer"
        DB["ComputeDb<br/>SQLite Database"]
        WANDB["WandB Metrics"]
        CONFIG["GPU Performance Config"]
    end

    VAL -->|"Validates Performance"| MIN
    VAL -->|"Sets Network Weights"| BT
    VAL -->|"Queries Metagraph"| META

    MIN -->|"Registers Hotkey"| BT
    MIN -->|"Manages Containers"| DOCKER
    MIN -->|"Provides SSH Access"| SSH

    API -->|"Allocates Resources"| MIN
    API -->|"Health Checks"| HEALTH

    VAL -->|"Stores Results"| DB
    VAL -->|"Logs Metrics"| WANDB
    MIN -->|"Updates Status"| WANDB

    CONFIG -->|"Configures Scoring"| VAL

Sources: README.md:1-535 , compute/__init__.py:1-93

Core Components

Validator System

Validators are responsible for measuring miner performance and maintaining network integrity. They operate continuous validation cycles that include hardware specification queries, proof-of-GPU benchmarks, and cryptographic challenge verification.

The validator system implements a sophisticated scoring mechanism based on GPU performance metrics, with base scores assigned to different GPU models and scaling factors for multiple GPU configurations. Validators with sufficient stake (validator_permit_stake = 1.0e4 TAO) can set network weights that determine miner rewards.

Key Classes and Constants:

• neurons/validator.py - Main validator process
• validator_permit_stake - Minimum stake requirement for validators
• specs_timeout = 60 - Timeout for hardware specification requests
• pog_retry_limit = 30 - Maximum retries for proof-of-GPU validation

Miner System

Miners contribute GPU computational resources to the network and respond to validator requests. They manage Docker containers for resource isolation, handle SSH-based resource allocation, and participate in proof-of-work challenges using Hashcat.

The miner system uses a priority-based request handling system where resource allocation requests (miner_priority_allocate = 3) take precedence over challenge responses (miner_priority_challenge = 2) and specification queries (miner_priority_specs = 1).

Key Classes and Constants:

• neurons/miner.py - Main miner process
• miner_hashcat_location = "hashcat" - Hashcat binary location
• miner_hashcat_workload_profile = "3" - High performance profile
• pow_timeout = 30 - Proof-of-work challenge timeout

Resource Allocation API

The Resource Allocation API is a FastAPI-based web service that provides external access to the compute network. It handles resource discovery, allocation requests, and health monitoring of active allocations.

The API implements RSA encryption for secure communication and maintains state through both local database storage and distributed WandB synchronization.

Sources: compute/__init__.py:21-77 , README.md:87-108

Validation and Challenge System

The subnet implements multiple validation mechanisms to ensure miner integrity and performance:

sequenceDiagram
    participant V as "Validator"
    participant M as "Miner"
    participant D as "Docker Container"
    participant BT as "Bittensor Network"

    Note over V,M: "Hardware Specification Phase"
    V->>M: "Send Specs Request"
    M->>V: "Return GPU/CPU Specs"

    Note over V,M: "Proof-of-GPU Phase"
    V->>M: "Request PoG Allocation"
    M->>D: "Create Container"
    D->>V: "Provide SSH Access"
    V->>D: "Run GPU Benchmarks"
    D->>V: "Return Benchmark Results"

    Note over V,M: "Challenge Phase"
    V->>M: "Send PoW Challenge"
    M->>M: "Execute Hashcat"
    M->>V: "Return Merkle Proof"

    Note over V,BT: "Weight Setting Phase"
    V->>V: "Calculate Scores"
    V->>BT: "Set Network Weights"

Proof-of-Work Configuration:

• pow_min_difficulty = 7 - Minimum challenge difficulty
• pow_max_difficulty = 12 - Maximum challenge difficulty
• pow_default_mode = "610" - BLAKE2b-512 hash mode
• pow_default_chars - Challenge character set including alphanumeric and special characters

Sources: compute/__init__.py:37-49 , README.md:437-450

Data Management and Monitoring

The system maintains state through multiple data persistence layers:

Component	Storage Type	Purpose
ComputeDb	SQLite	Local miner stats, scores, allocations
WandB	Distributed	Cross-validator metrics, distributed state
Configuration	YAML/ENV	GPU performance benchmarks, API keys

The monitoring system uses WandB for distributed state management and metrics collection, with separate runs for validators and miners to track performance and resource utilization.

Version Management:

• __version__ = "1.9.0" - Current subnet version
• __minimal_miner_version__ = "1.8.5" - Minimum required miner version
• __minimal_validator_version__ = "1.8.8" - Minimum required validator version

Sources: compute/__init__.py:20-26 , README.md:297-303

Network Communication

The subnet uses custom Bittensor synapse protocols for component communication:

graph LR
    subgraph "Protocol Layer"
        SPECS["Specs Protocol<br/>Hardware Queries"]
        ALLOC["Allocate Protocol<br/>Resource Requests"]
        CHALLENGE["Challenge Protocol<br/>PoW Verification"]
    end

    subgraph "Transport Layer"
        AXON["Custom Axon<br/>Miner Endpoints"]
        SUBTENSOR["Custom Subtensor<br/>Network Interface"]
    end

    SPECS --> AXON
    ALLOC --> AXON
    CHALLENGE --> AXON

    AXON --> SUBTENSOR

The communication system includes blacklist management for suspected exploiters and trusted validator lists to maintain network security and integrity.

Sources: compute/__init__.py:59-92 , compute/utils/parser.py:8-170

For detailed information about specific components, see the Validator System, Miner System, Resource Allocation API, and Communication Protocols sections.
